| Product Attribute | Attribute Value |
|---|---|
| Cable Length | 2 m |
| Cable Type | PUR-Cable |
| Connection Type | Cable |
| Connector Type | 2 m PUR-Cable |
| Current Rating | 250 mA |
| Frequency, Switching | 1.4 kHz |
| IP Rating | IP67 |
| Material | PBT |
| Measurement Range | 2 mm |
| Mounting Style | Flush |
| Mounting Type | Flush |
| Operating Voltage Range | 10-36 VDC |
| Output | PNP-NO |
| Primary Type | Inductive Proximity Sensors |
| Protection Class | Protection Class III |
| Sensing Range | 2 mm |
| Shielding | Shielded |
| Supply Voltage | 10-36 VDC |
| Temperature, Ambient | -13 to 176 F (-25 to 80 C) |
| Type | IN5121 |
Overview
In all automated processes, sensors are necessary to provide the PLC with information. They supply the necessary signals for positions and limits, or serve as pulse pick-ups for counting tasks or for monitoring rotational speed. They offer ideal characteristics compared to mechanical switches: non-contact operation free from any wear and tear, high switching frequencies and accuracy. In addition, they are insensitive to vibration, dust and moisture. Inductive sensors detect all metals without contact.
Ifm’s small rectangular inductive sensors have a compact design and are perfectly suited for applications where space is at a premium. This makes them an ideal choice for robotics, assembly and handling applications. The small sensors reach switching frequencies of up to 2,000 Hz - and this over the whole temperature range.
Features:
